large format printer with Konica head from China manufacturer

Product Detail

Model No.: Smark3208A

Production Capacity: 100 sets

Delivery Date: within 7 days after receive...

Type: Digital Printer

Usage: Others

Color: Y M C K

Automatic Grade: Automatic

Means of Transport: Ocean,Land,Air

Packing: plywood

Plate: Screen Printer

Color & Page: Multicolor

Brand Name: T-JET

Dimensions(L*W*H): L4600*W1000*H1350mm

1.easy maintenance
2.printing output: 1000sqm one day
3.one year warranty
4.3.2M printing width
5.competitive price

Model		SMARK3208A
Printhead		Konica Minolta Printhead (KM51214/42PL)
Mumber of Printhead		4Heads 8Heads
Maximun Print Width		3,200mm(10 feet)
Print Speed*		Draft 90sqm/H 180sqm/H

		Standard 45sqm/H 90sqm/H

		Highquality 22.5sqm/H 45sqm/H
Media	Max.width	3,300mm
	Max.Weight	Roll Media:150kg
	Type	Frontlit,Backlit,Vinyl,Polyester,Window,Film,Mesh,Leather,BacklitFilm,Blue Back Paper…
	Thickness	4mm(Max.)
Heating System		Pre/Post Heater, Cooling FanSystem
Auto Media Feeding& Take-up System		Equipped (Take upsystem option)
Ink	Type	Solvent,
	Capacity	1L or 5L per Color MainTank
Auto Cleaning System		Positive PressureCleaning,Anti-Clogging Flash Function&Capping System
Print Interface		USB 2.0
Power Specification		AC 220V/230V 50Hz/60Hz1350W
Operational Environment		Temperature: 20°C-28°C Humidity :40%-60%
Compatible RIP Software		Photoprint RIP, UltraprintRIP
Dimension &Weight	Machine	*L4600W1000H1350mm 550KG*
	Packae	*L4700W1200H1450mm 600KG*
